SPECIFICATIONS:
RATING:
1A
INSULATION RESISTANCE:
100 MOhm min
CONTACT RESISTANCE:
30 mOhm max
DIELECTRIC WITHSTANDING VOLTAGE:
500V AC
LIFE:
1500 cycles min
Part number:300/272JFW31-R Select contact plating option F G J Select shell option T N Select color option W I B
Selection explanation:
Contact plating:
F - gold flash over 50u" nickelG - gold flash over 30u" Pd-Ni over 50u" nickelJ - 30u" gold over 50u" nickel
Shell option:
T - tin platedN - nickel plated
Insulator color option:
B - blackI - ivoryW - frost white
